Stereo 40 MK IV 6L6 Specification and features:
- All hand wired point to point, no printed circuit board
- Class A, all Triode front end
- Ultralinear or Triode option
- 4x 6L6 KT66 compatible valves
- 4x 6SN7/CV181 first stage valve and phase splitter
- 2x 30w continuous Ultralinear output
- 2x 15 Watts in Triode mode (option)
- Remote control with high quality ALPS motorised pot (option)
- Signal to noise level -90db
- Freq response better than 20hz-20kHz +0 – 1db
- Power bandwidth 30Hz-30kHz -3 dB
- Total harmonic distortion 0.2% at full output
- Suitable for 4, 8, and 16ohm loudspeakers
- Supplied with valve cover.
- Choke regulated power supply
- SCR audio caps, or Mundorf silver/gold in oil upgrade option
- Audiophile quality internal audio cable
- Custom hand wound Tertiary output transformers
- Audiophile Gold plated Input & speaker terminals
- Three line inputs: CD, Tuner, Aux
- Input sensitivity 250mv
- Comprehensive manual supplied
- Power requirement 230-240volts (117v adjustable)
- Power consumption 100 W Min, 195 W
- 39cmW, 41D, 23H, 22kg (allow for ventilation)
